Main features:
- 5.6" color LCD touch screen with refreshed User Interface,
- new functions: inrush current measurement, data flagging, inverter efficiency, mains signaling, harmonic power,
- waveform real-time display and recording (4 voltages/4 currents),
- half cycle RMS measurement (voltage and current),
- measurement of TRMS currents up to 6000 A (with additional current clamps),
- measurement in 1-phase and 3-phase systems (3- and 4-wire),
- measurement of voltage, current, harmonics, power, energy, inrush current, flicker and others,
- graphical presentation of data in a waveform and vector diagram,
- record of events: interruptions, dips, overvoltages,
- power quality according to EN-50160 standard or user-defined limit,
- internal memory for data recording (recording period from 2 hours to 1 year),
- registration of user-defined parameters in the 32GB internal memory,
- Ethernet interface for remote operation of the analyzer,
- USB Host to move archive data and screenshots to an external USB memory,
- safety standards: EN 61010-1, CAT III 1000V / CAT IV 600V,
- IP53 protection grade.
